Description
« Compatible with E Ink Scarlet evaluation kit »
13.3" Spectra 6 ePaper Display (ED2208-NCA) is a reflective electrophoretic E Ink® Spectra 6 technology display module based on active matrix TFT substrate. It has 13.3" active area with 1200 x 1600 pixels and 3 : 4 aspect ratios. The display is capable to display images at Black/White/Red/Yellow/Blue/Green depending on the display controller and the associated waveform file it used.
• This model is suitable for the applications of signage, e.g. bus stop signs and medical bed cards.
-
Note
● Please make sure you are in possession of a E Ink Scarlet Driving Board and Scarlet Accessories.
Introduction
About This Item
Features
• Display Black/White/Red/Yellow/Blue/Green colors
• High contrast electrophoretic imaging film
• Ultra-wide viewing angle
• Ultra-low power consumption
• Pure reflective mode
• Bi-stable image
• Portrait mode
• Operation temperature range: 0℃~50℃
Package content
• 13.3" ePaper Display (ED2208-NCA)
Specification
Product Information
Item
Specification
Screen Size
13.3 inch
Backplane Type
Glass
Display Resolution
1600 (H) × 1200(V) pixel
Active Area
202.8 (H) x 270.4 (V) mm
Outline Dimension
208.8 (H) x 284.7 (V) x 0.85(D) mm
Pixel Pitch
0.169(H) × 0.169(V) mm
Pixel Configuration
Square
Module Weight
50 ± 10 g
Surface Treatment
Anti-glare treatment for protective sheet (PMC (>HB))
